7 sTrucTure anD funcTiOn
7.1

structure

The manually actuated diaphragm valve consists of a manual actuator
and a 2/2-way valve body.
7.2 Type description
The types differ in the body.
7.2.1 Type 3232, 3233 and 3233 K
Fig. 5: Example of the 2/2-way valve type 3232, 3233
and 3233 K
12
Handwheel with position
indicator (see chapter "7.3.1")
Attachment
Diaphragm body
Port connection
english
Type 3232, 3233, 3233 K, 3234,

Structure and Function

7.2.2 Types 3234, 3235 and 3239
type Body
T-Valve
T-Valve body
Type 3234
Tank bottom Tank bottom
valve valve with
Type 3235 welding flange
Y-Valve
Y-Valve body
Type 3239
Tab. 7: Structure. Types 3234, 3235 and 3239
3235, 3239
structure
