maximum permitted medium pressure
Orifice max. switchable medium pressure [bar]
(diaphragm
handwheel and attachment stainless steel
size)
epdm / fKm
dn [mm]
65 5
80 5
100 5
Tab. 6: Maximum permitted medium pressure
6.4 Description of the type label
Orifice
(Diaphragm size)
Type
3233
TG44
00442376
Identity number
Port connection,
Max. medium pressure
Fig. 2: Description of the type label (example)
10
ptfe/advanced ptfe/
laminated advanced
ptfe
5
5
5
Seal material
Body material
25,0 EPDM VS
Pmed 10bar
W36LP
english
Type 3232, 3233, 3233 K, 3234,
Technical data
6.5 labeling of the forged body
Company logo
Material
Pressure stage
Fig. 3:

Labeling of the forged body

3235, 3239
Batch number/
manufacturer sign
Production number/
order number
(F-part)
Serial number
Surface quality
code
Customer-specific
text (optional)
Connection orifice
and pipe dimensions
