Parameterization and configuration

8.3.4.7.12 Parameter list (PNU 980)

This parameter is supported by the measuring system as of software version 2.5.0. This parameter
contains all parameter numbers supported by the measuring system. The parameter numbers are
written into the subindexes in ascending order. The value 0 in a subindex marks the end of a
parameter list.
PNU
980
Meaning
List of all implemented parameters
Data type
Array [n] Unsigned16
Access
read
Subindex
Meaning
0
0x039A: Telegram selection (PNU 922), ....................................... see Page 138
1
0x039D: Tolerated master sign-of-life faults (PNU 925), ............... see Page 138
2
0x03C4: Device identification (PNU 964), ...................................... see Page 138
3
0x03C5: Profile identification (PNU 965), ...................................... see Page 139
4
0x03CB: Parameter storage (permanent) (PNU 971), ................... see Page 139
5
0x03CC: Device RESET / parameter activation (PNU 972), ......... see Page 139
0x03CE: B M P Access – Identification (PNU 974), ....................... see Page 140
6
7
0x03CF: Encoder object identification (PNU 975), ........................ see Page 140
8
0x03D3: Sensor Format (PNU 979), .............................................. see Page 141
9
0xEA60: Velocity reference value N2/N4 (PNU 60000), ................ see Page 137
10
0xEA61: Velocity value normalization (PNU 60001), ..................... see Page 137
11
0xFDE8: Preset value 32 bit (PNU 65000), ................................... see Page 130
12
0xFDE9: Operating status (PNU 65001), ....................................... see Page 131
13
0xFDEC: Function control (PNU 65004), ....................................... see Page 135
14
0xFDED: Parameter control (PNU 65005), .................................... see Page 136
15
0xFDEE: Scaling: Measuring units per revolution (PNU 65006), .. see Page 136
16
0xFDEF: Scaling: Total measuring range (PNU 65007), ............... see Page 137
17
0x0000: End of parameter list
 TR-Electronic GmbH 2017, All Rights Reserved
Page 142 of 168
TR-ECE-BA-DGB-0132 v21
Printed in the Federal Republic of Germany
07/21/2022
