8.3.4.3 Function control (PNU 65004)

This parameter is supported by the measuring system as of software version 2.5.0. Using the function
control, measuring system-related functions can be independently enabled or disabled, the code
sequence can be set, and the encoder type can be read out.
PNU 65004
Meaning Function control
Data type Unsigned32
Access read/write
Activation PNU 972
Storage PNU 971
Bits Definition
Code sequence, see Chapter 8.3.3.1 on Page 120
0
0: CW
1: CCW
Encoder Class 4 functionality, see Chapter 8.3.3.2 on Page 120
1
0: disabled
1: enabled
Preset affects XIST1, see Chapter 8.3.3.3 on Page 121
2
0: enable
1: disabled
Scaling function control, see Chapter 8.3.3.4 on Page 121
3
0: disabled
1: enabled
Alarm channel control, see Chapter 8.3.3.5 on Page 121
4
0: disabled
1: enabled
Compatibility mode V3.1, see Chapter 8.3.3.6 on Page 122
5
0: enable
1: disabled
Encoder type, see also Chapter 8.3.4.2.2 on Page 132
6
0: Shaft encoder, resolution in steps per revolution
1: Linear encoder, resolution in nm per step
7 - 31 reserved
