8.4.5.1.3 SSI mono time

The parameter mono time defines the mono time of the SSI interface.
Selection Value
20 µsec 0
15 µsec 1
50 µsec 2
500 µsec 3

8.4.5.1.4 SSI output data

The parameter output specifies the type of data that is output on the SSI interface.
Value Description
1 Position (32 bit Unsigned)
2 Speed (16 bit Signed)
3 Position+Speed (48 bit, behind each other)

8.4.5.1.5 SSI special bit

The parameter special bit is currently not supported.

8.4.5.2 End switch parameters

The parameters for the limit switch function are currently not supported.

8.4.5.3 Preset switch parameters

The parameters preset switch 1 and preset switch 2 contains each the preset value which is
set as a new position value when the associated external preset input 1 or 2 is connected.
Unsigned64
Word X+0
Bit 0-15
– 2
0
Data 2
Lower limit
Upper limit
 TR-Electronic GmbH 2017, All Rights Reserved
Page 156 of 168
Description
the mono time is 20 µs
the mono time is 15 µs
the mono time is 50 µs
the mono time is 500 µs
Danger of physical injury and damage to property due to an actual value
jump during execution of the preset adjustment function!
 The preset adjustment function should only be executed when the
measuring system is stationary, or the resulting actual value jump must be
permitted by both the program and the application!
X+1
16-31
– 2
15 16
2
0
Programmed total measuring range in steps – 1
