Troubleshooting and diagnosis options

10.5 Miscellaneous faults

Fault Cause
Strong vibrations
Measuring system
Position jumps Electrical faults, EMC
Extreme axial and radial load
on the shaft or a scanning
defect.
 TR-Electronic GmbH 2017, All Rights Reserved
Page 168 of 168
Solution
Vibrations, impacts and shocks, e.g. on
presses, are dampened with so-called "shock
modules". If the error occurs repeatedly
despite these measures, the measuring
system must be replaced.
Isolated flanges and couplings made of plastic
may help against electrical faults, as well as
cables with twisted pair wires for data lines.
The shielding and line routing must be
executed in accordance with the Equipment
Mounting Directives for the respective field
bus system.
Couplers prevent mechanical stress on the
shaft. If the error occurs repeatedly despite
these measures, the measuring system must
be replaced.
