8.3.4.2.5 Warnings (PNU 65001.04)

The parameter in Subindex 4 displays the current measuring system warnings.
Bits Definition
0 Frequency exceeded
1 Overtemperature
2 Light control reserve
3 CPU watchdog status
4 Operating time limit
5 Battery undervoltage
6 Reference point
7 - 31 reserved

8.3.4.2.6 Supported warnings (PNU 65001.05)

The parameter in Subindex 5 displays the warnings supported by the measuring system.
Bits Definition
0 Frequency exceeded
1 Overtemperature
2 Light control reserve
3 CPU watchdog status
4 Operating time limit
5 Battery undervoltage
6 Reference point
7 - 31 reserved

8.3.4.2.7 Encoder Profile Version (PNU 65001.06)

The parameter in Subindex 6 contains the profile version implemented in the measuring system.
Bits Definition 4.1
0 - 7 0x01 (LSB)
8 - 15 0x04 (MSB)
16 - 31 0x0000, reserved
* Encoder Profile 4.2 is supported by measuring systems as of software version 2.5.0.

8.3.4.2.8 Offset value 32-bit (PNU 65001.08)

The offset value in Subindex 8 is calculated internally during execution of the preset function and
offsets the position value by the calculated value. Each time the preset function is executed, the re-
calculated value is permanently stored and specified as a scaled value according to the set resolution.
Integer32, complement of two
Byte
Bit
Data
Printed in the Federal Republic of Germany
07/21/2022
Version no.: 0x0401
X+0
31-24
– 2
31 24
2
TR-ECE-BA-DGB-0132 v21
= 0
Always 0
Always 0
Always 0
Always 0
Always 0
Always 0
Always 0
= 0
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
Definition 4.2 *
0x02 (LSB)
0x04 (MSB)
X+1 X+2
23-16 15-8
– 2
23 16 15
2 2
=1
-
-
-
-
-
-
-
=1
-
-
-
-
-
-
-
Version no.: 0x0402
X+3
7-0
– 2 – 2
8 7 0
2
