For the fastening, proceed as shown in the following figure:
c) Removal
• Remove the front control panel.
• Carefully remove the plastic frame in the front of the system by bending it slightly to the outside and pulling it off
from the unit.
• Insert the two unlocking keys into the lateral slots in the installation frame until the device unlocks.
• Loosen the screw pin at the back of the device if required.
• Carefully pull out the radio with the unlocking keys from the installation frame.
• Remove all plug connections at the back of the unit.
d) Hands-Free Microphone
The microphone for the hands-free system can be attached to the sunblind, the steering column cover or any other
suitable position inside the vehicle.
The microphone and connection line must never be in the airbag trigger area.
• Attach the hands-free microphone in a suitable position with the clamp or the enclosed adhesive holder.
• Place the connection line to the radio installation slot.
38
