10.2 microspeed® uni control unit with cooling unit
GD670
Mains voltage ranges
(Current intake)
Frequency
Protection class (acc. to IEC 60601-1)
Output voltage
Output current
Device fuse
Breaking capacity
Delivery rate of cooling pump
(at maximum dosage setting)
Weight
Dimensions (L x W x H)
Application component
EMC
Norms

10.2.1 Factory settings

Parameter
Motor speed range upper limit for high-
speed motors GD676 and GD677
Motor speed range upper limit for low-
speed motors GD678 and GD679 with
micro-Line coupling
Motor speed range upper limit for low-
speed motors GD678 and GD679 with
micro-Line coupling
Motor speed range upper limit for low-
speed motors with mini-Line coupling
GD674 and pistol handpiece GD684
Oscillating or tapping mode (for pistol
handpiece GD684)
Rotation angle, oscillating mode
(for pistol handpiece GD684)
Rotation angle for tapping mode
(for pistol handpiece GD684)
Motor speed range upper limit for shaver
handpiece GD682, "Shaving" mode
Motor speed range upper limit for shaver
handpiece GD682, "Reaming" mode
Oscillation frequency in "Shaving" mode
100-120 V~ (4.2-3.2 A)
220–240 V~ (1.7–1.5 A)
50-60 Hz
Ι
max. 35 V
max. 8.5 A
T 6.3 A
H (1 500 A at 250 V/50 Hz)
approx. 80 ml/min
8.9 kg
305 mm x 305 mm x 175 mm
Type BF
IEC 60601-1-2
IEC 60601-1
Setting/Status
60,000 1/min
20,000 1/min
Saw program
16,000 1/min
16,000 1/min
deactivated (Instruction
menu)
210° clockwise, then 210°
counterclockwise at gear
reduction 16:1
270° clockwise, then 90°
counterclockwise at gear
reduction 16:1
800 1/min
6,000 1/min
1 s left, 1 s right
Parameter
Motor type-specific standard settings for
speed-up ramps
Motor type-specific standard settings for
slow-down ramps
Pump operation
Pump flow
Language
Acoustic alarm/notification signal

10.3 Low-speed motors

10.3.1 Low-speed motors with micro-Line coupling

Art. no. Power output (in W)
GD678 150
GD679 100
Motor speeds/setting
Note
The speed figures refer to motor speeds.
Parameter
Step width for speed range upper limit setting
Motor direction settings
(optical and acoustic notification for left
rotation)
Maximum speed range upper limit
- for motor GD678
- for motor GD679
Minimum speed range upper limit
Minimum speed setting
Factory setting
Saw program (with limited motor speed)
Setting/Status
Standard
Standard
OFF
2/3-dosage
English
max. volume
Design
Standard
Short
Speed/Setting
1,000 1/min
- right rotation
- left rotation
- 30,000 1/min
- max. 40,000 1/min
1,000 1/min
500 1/min
20,000 1/min
max. 16,000 1/min
