7.4.2.

Swivel kiln stand

Step Action required
We have designed a swivelling kiln stand (figure 17) that
1 will allow you to adjust the height to your own
requirements.
First detach the castors (only for models up to
2
TE 75 MCC+).
Now loosen the black plastic feet and remove them from
3
the kiln stand.
Finally remove the plastic cap from the upper part of the
4
kiln stand.
Check the tensioning belts of the stainless steel kiln
5
casing beforehand and tighten them slightly if necessary.
Applies only to Ecotop:
6.1) Make a note of or take a picture of which side the
floor insulation panel is placed facing up in the kiln
6
stand.
6.2) Carefully remove the floor insulation panel.
6.3) Carefully lay the panel flat on an even surface.
42 / 161 - EN -
Illustration
