Installation And Connection; Control Card Version C; Assignment Of The Terminal Strip X2A - KEB COMBIVERT Betriebsanleitung

4.
4.1
4.1.1
PIN Function
1..4 without function
5 Analog output 1
6 Analog output 2
7 without function
8 Analog mass
9 Analog mass
10 without function
11 without function
12 without function
13 without function
14 Slave input
15 without function
16 Start
17 Reset
18 Transistor output 1
19 Transistor output 2
20 24 V-output
21 without function
22 Digital ground
23 Digital ground
24 Relay 1 / NO contact
25 Relay 1 / NC contact
26 Relay 1 /
switching contact
27 Relay 2 / NO contact
28 Relay 2 / NC contact
29 Relay 2 /
switching contact

Installation and Connection

Control Card Version C

Assignment of the Terminal Strip X2A

1 2 3 4 5 6 7 8 9
Name Explanation
- -
ANOUT1 Analog output of the DC output current
0...10 VDC ^ 0...
ANOUT2 Analog output of the DC voltage
0...10 VDC ^ 0...1000 VDC
- -
COM Mass for analog in- and outputs
COM Mass for analog in- and outputs
I1 -
I2 -
I3 -
I4 -
I5
only interconnected operation 00.R5.0DM-I000
I6 -
ST Thyristors switched through
Error reset during opening
RST Reset; only possible in fault condition
O1 „Run"; is set, if the thyristors are switched trough
O2 „Error" is set, if the unit switched off on error
U Power supply for digital inputs (max. 100 mA)
out
- -
0V Reference potential for digital in-/outputs
0V Reference potential for digital in-/outputs
RLA relay output
RLB Ready for operation signal
RLC
FLA relay output
FLB phase error warning
FLC
Installation and Connection
X2A
10 11 12 13 14 15 16 17 18 19 20 21 22 23
200 %
24 25 26 27 28 29
-
Voltage range:
0...±10V
Ri = 100 Ω
Resolution: ±10 bit
Ri = 2,1 kOhm
Scan time: 4 ms
max. 30 V DC, 0,01...1 A
GB - 37
