17 Warranty

The statutory warranty period applies. If the product is defective, please contact the manufacturer's branch in your
country (see dometic.com/dealer) or your retailer.
For repair and warranty processing, please include the following documents when you send in the device:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
Note that self-repair or nonprofessional repair can have safety consequences and might void the warranty.

18 Technical data

Technology
Nominal voltage
Nominal capacity, at 25 °C
Nominal energy, at 25 °C
Number of cells in series
Recommended maximum dis-
charge current
Maximum supported discharge
current
End of discharge voltage
Recommended maximum charg-
ing current
Maximum supported charging
current
End of charging voltage
Number of cycles 80 % DOD
Operating temperature, dis-
charge
Operating temperature, charge
(TLB100, TLB120 and TLB150)
Operating temperature, charge
(TLB100F, TLB120F and TLB150F)
Storage temperature
Self-discharge
Maximum humidity
Pole connection size
Weight
Dimensions (W x D x H)
18
TLB100/TLB100F
100 Ah
1280 Wh
100 A
200 A / 60 s
50 A / 0.5 C
100 A / 1 C
12.8 kg
341 mm × 190 mm × 176 mm
TLB120/TLB120F
LiFePO4
12.8 V DC
120 Ah
1536 Wh
4
120 A
10.5 V ± 0.1 V
60 A / 0.5 C
120 A / 1 C
14.4 V ± 0.2 V
3500
–   20 ... 60 °C
–   10 ... 45 °C
–   30 ... 45 °C
≤ 5 % / month
–   20 ... 45 °C
95 %
M8
13.5 kg

TLB150/TLB150F
150 Ah
1920 Wh
135 A
200 A / 150 s
75 A / 0.5 C
150 A / 1 C
16.1 kg
