Led Indications - Dometic POWER & CONTROL TEMPRA TLB100 Bedienungsanleitung

fig.  on page 5
To switch off the battery together with the Bluetooth® function using the On/Off switch, press and hold it
for 8 seconds until LED
To switch off the battery with the On/Off switch leaving the Bluetooth® function active, press and hold it
4 seconds until LED
To deactivate the battery for longer storage, push the DIP switch 6
Shutting down by the smartphone application
fig.  on page 6
1. Tap on the menu icon
2. Tap on the Bluetooth® icon
3. Tap on the Battery switch icon
The battery will switch off after a few seconds, with the Bluetooth® function remaining active.

LED indications

LED indication
Green - steady
Green - flashing
Blue - flashing
Purple - flashing
Red - flashing
Orange - flashing
Orange - steady
Off
Charging
When charging the battery with an external charger, observe the following guidelines:
• Use chargers intended for charging lithium (LiFePO4) batteries. Other type of charger will reduce battery life.
• The charger must not perform any desulfation action.
• When using a configurable charger, set the contant current/constant voltage (CC/CV) option with the follow-
ing values:
• Set the end of charge voltage to 14.4 V.
• Set the recommended maximum charging current for the battery.
• The maximum charging voltage should not exceed 14.5 V.
• When the battery is fully charged and the display shows 100% state of charge, disconnect or turn off the charg-
er.
TLB100F, TLB120F and TLB150F models: When the battery is being charged at temperatures below 0 °C, the cell
heating system is activated. The cell heating system uses the charger's energy to power itself and, once the ideal
charging temperature is reached, the heating is switched off and charging begins. If, during charging, the tempera-
ture raises above the permissible range, the internal battery management system (BMS) will limit the charge to pre-
serve battery life.
starts flashing in purple.
starts flashing in blue.
.
.
.
Battery is starting up. No voltage present at the terminals.
Battery is active. Voltage present at the terminals.
Battery is powering down. Bluetooth® active. No voltage present at the terminals.
Battery is powering down. Bluetooth® not active. No voltage present at the terminals.
Battery alarm. No voltage present at the terminals.
Temperature range limit reached. Voltage present at the terminals.
Battery inactive. Bluetooth® active. No voltage present at the terminals.
into off position.
Description
Firmware update.
EN
for
15
