NOTICE! Damage hazard
To prevent damage to the equipment, deactivate all loads and the charger before battery installation.
NOTICE! Damage hazard
Battery cables must not be connected to the battery in reverse polarity, otherwise damage to the device
may occur.
NOTICE! Damage hazard
To prevent damage to the equipment, always connect the positive cable first.
Note The battery can only be installed in the upright position on a horizontal surface.
fig.  on page 1
1. Remove the terminal protection caps
2. Install the battery cables
3. To ensure a secure electrical contact, tighten the fasteners to the end of the threads, without using excessive
force.
4. Install the terminal protection caps
5. If possible, secure the battery to the floor to avoid unexpected movements during the journey.
Note It is also allowed to connect automotive terminal clamps with M8 screws and appropriate washers.
NOTICE! Damage hazard
Never connect multiple batteries in series.
Display installation (Optional)
fig.  on page 1
1. Slide the bracket down
2. Tilt the bracket away from the display
3. Slide the bracket up
fig.  on page 2
4. Using the bracket, mark the screw holes
5. Drill the screw holes
6. Pull the communication cable through the passage hole
7. Mount the bracket on the mounting surface using the supplied screws.
fig.  on page 2
8. Connect the connection cable to the display
9. Mount the display on the bracket.
and
to the corresponding terminal
and .
.
.
.
and the cable passage hole
and the cable passage hole
.
using appropriate fasteners
.
both on the mounting surface and the bracket.
.
.
on the mounting surface.
