Replacing Batteries - eQ-3 homematic IP HmIP-eTRV-2 Montage- Und Bedienungsanleitung

• Boost function: Press the control wheel (E)
shortly to activate the boost function for heating
up the radiator quickly and briefly by opening the
valve. There will be a pleasant room temperature
right away because of the radiated heat.
The operating lock of the radiator thermostat can
be activated and deactivated via the Homematic IP
app. Tap on the menu symbol in the top left of the
screen of your app and select the menu item "De-
vice overview". Select your radiator thermostat to
switch the operating lock "ON" or "OFF".
7

Replacing batteries

If the symbol for empty batteries (
play or in the app, please replace the used batteries by
two new LR6/mignon/AA batteries. You must observe the
correct battery polarity.
To insert the batteries into the radiator thermostat, please
proceed as follows:
Push the battery compartment cover (D) to the
•
back and downwards to remove it from the de-
vice (see figure 7).
• Remove the (old) batteries.
• Insert two new 1.5 V LR6/mignon/AA batteries
into the battery compartment, making sure that
you insert them the right way round (see figure 8).
• Close the battery compartment (D).
Replacing batteries
) appears in the dis-
51
