General system information

Device overview (see figure 1):
(A) Metal nut
(B)
Display
(C)
System button (pairing button and LED)
(D) Battery compartment cover
(E)
Control wheel/boost button
Display overview (see figure 2):
(F)
(G)
(H)
(I)
(J)
(K)
(L)
(M)
4 General system information
This device is part of the climate control solution of
Homematic IP and works with the HmIP radio protocol.
All devices of the climate control solution can be config-
ured comfortably and individually with a smartphone via
the Homematic IP app. The available functions provided
by the Homematic IP system in combination with other
components are described in the Homematic IP User
Guide. All current technical documents and updates are
provided at www.homematic-ip.com.
40
Valve information
Setpoint temperature
Manual operation
Boost mode
Operating lock
Open window symbol
Radio transmission
Battery symbol
