General system information

Device overview (see figure 1):
(A) Union nut
(B) Battery compartment (and cover)
(C) Display
(D) System button (teach-in button and LED)
(E) Minus button
(F) Plus button
(G) Menu/Boost button
Display overview (see figure 2):
0 6 12 18 24
Th Fr Sa Su
Mo Tu We
AUTO
MANU
AUTO
BOOST
Offset
Prg
Mo Tu We Th Fr Sa Su
AUTO
* see see „6 Configuration menu" on page 43
4 General system information
This device is part of the Homematic IP smart home system and
works with the Homematic IP protocol. All devices of the system can
be configured comfortably and individually with the user interface
of the Central Control Unit CCU3 or flexibly via the Homematic IP
smartphone app in connection with the Homematic IP cloud. All
available functions provided by the system in combination with other
components are described in the Homematic IP Wired Installation
Guide. All current technical documents and updates are provided at
www.homematic-ip.com.
36
Overview of heating phases
Setpoint temperature
Time and date*
Operating lock*
Open window symbol
Radio transmission
Empty batteries
Holiday mode*
Automatic operation*
Manual operation*
Boost mode
Offset temperature*
Programming a heating profile*
Days of the week
