data via the ANT+ FE-C protocol even if they're connected
via Bluetooth.
When a home trainer does not send workout data via ANT+
FE-C, the RIZER cannot work its Simulation mode.
To use handlebar rotation, RIZER sends data via both the
ANT and Bluetooth protocols.
STATUS LED LIGHT
There are 3 (three) different types of LED light on the RIZER:
2 on its base that indicate connection status with the home
trainer and/or training software; one on the keyboard that
indicates the current mode.
LED lights on the base
The two LED lights on the base indicate the connection
status.
Right LED light.
LED light off means that the RIZER has not conducted the
pairing procedure with the home trainer. To use RIZER
the pairing procedure with the home trainer must be
conducted.
Blinking green LED light means the RIZER is waiting to
connect to the home trainer.
A fixed green LED light means the RIZER has connected to
the home trainer.
Left LED light.
Blinking blue light means the RIZER is ready to connect to
the software.
A fixed blue LED light means the RIZER is connected to a
software and/or the RIZER configuration app.
Both blue LED lights means that RIZER is updating its
firmware.
Keyboard LED light
On: RIZER is in Simulation mode
Off: RIZER is in Manual mode
Blinking: LED light might blink after two different operations:
- home trainer pairing: after a pairing command the LED
light starts blinking for a few dozen seconds.
- profile change: after a profile change command the LED
light blinks as many times as the number of the selected
profile, For instance, 4 blinks means that profile number
#4 has been selected.
STAND-BY
RIZER enters stand-by mode after 15 minutes of inactivity,
that is 15 minutes when home trainer speed is zero and the
handlebar sensor picks up no movements.
To reactivate it just tap on one of the keys in the top part
of the RIZER.
Alternatively, you can reactivate the RIZER by rotating the
handlebar over 10° (left of right).
COMPATIBLE HOME TRAINERS
RIZER is compatible with all home trainers that support the
ANT+FE-C profile, though for it to work properly with the
RIZER, the home trainer must be able to let the bicycle
frame rotate freely.
If it isn't so, using RIZER might risk damaging the frame in
the spot where it's locked in with the home trainer.
Check RIZER compatibility with the home trainer
manufacturer.
06_USER PROFILES
To make it possible for multiple people in the same family
to use the RIZER or to be able to use different types of
bicycles it is possible to configure up to 5 user profiles that
can be set with parameters identifying the user and/or the
bicycle being used.
PROFILE SETTINGS
Setting parameters in the profiles can only be done via
the RIZER app. The user profile contains the following
parameters:
Profile name: you can name each profile (10 digits max)
so it's easier to identify;
Cyclist weight: on home trainers that do not send gradient
data to the RIZER, the RIZER needs to know the cyclist
weight to be able to accurately calculate the gradient to
simulate.
Bicycle weight: on home trainers that do not send
gradient data to the RIZER, the RIZER needs to know
the bicycle weight to be able to accurately calculate the
gradient to simulate.
Max gradient: value (percentage) that limits RIZER positive
range. Value must be between 0% and 20%. For instance,
by setting 15, RIZER will never get over 15% tilt;
Min gradient: value (percentage) that limits RIZER
negative range. Value must be between 0% and 10%. For
instance, by setting 5, RIZER will never get under -5% tilt;
These settings are also useful should the crank touch the
floor while simulating gradient.
Wheelbase: value expressed in mm that indicates
the wheelbase of the two bicycle wheels, necessary
to calculate the cursor range, to which the front fork is
connected, to set the proper inclination
Safety: Safety parameter. This parameter enables or
disables the function that brings the bicycle to zero tilt after
5 seconds at zero speed.
Default values for profile 1 are:
- name: default;
- bicycle weight: 10 Kg;
- cyclist weight 75 Kg;
- max gradient limit: 20%;
- min gradient limit: -10%;
- wheelbase: 1000 mm;
- safety: active;
To select a profile different from the first one you must first
create it and fill out all the parameters. To create a new
profile you must use the RIZER configuration app.
