Grouping
CH
1
The factory identification of the wheel gripper is displayed here. Do not change this without the approval of the dealer or
manufacturer
ID
2
The factory identification of the wheel gripper is displayed here. Do not change this without the approval of the dealer or
manufacturer.
N
3
Displays the number of axles set.
It must exactly match the actual number of axles of the lifted vehicle.
Note that N indicates the number of axles, but not the number of wheel grippers. Check that the setting is correct before
saving the grouping option.
N option
4
Press a number to select
Press the yellow area to select
Identification Option
5
Press to select an identifier
Each wheel gripper that is to be connected to the overall system must have a different identifier.
The identification of each wheel gripper must correspond to the position of the wheel gripper.
ZigBee
6
Press this button to save the grouping option and return to the settings page.
ESC
7
Press this key to return to the setting page or to save the grouping setting.
