Hydraulic Circuit Diagram - ATH RG 5.5 WG Bedienungsanleitung

6.2

Hydraulic circuit diagram

11
5
1
Gear pump
3
Motor DC 24 V
5
Pressure relief valve
7
Lowering valve
9
Lowering valve
11
Throttle check valve
® Copyright ATH-Heinl GmbH & CO.KG, All rights reserved / Misprints and technical changes reserved
6
4
2 3
1
Release date: 10-2022 / Product manufacturer ATH-Heinl GmbH & CO. KG
7
10
2
Oil filter
4
Check valve
6
Hydraulic cylinder
8
Lowering valve
10
Lowering speed valve
8
9
45
