INSTALL THE ELEVATOR ASSEMBLY
4. Check the two bolts on the pre-assembled
lift bracket (22) for tightness.
5. Connect the end of the pin lanyard (25) to
the hole on the bracket (22).
6. Insert the handle assembly through the
pole mount assembly.
7. Lock the pole assembly in place at the 10'
(3.05 m) mark with the pin (24).
#25
19
Elevator Assembly
#22
#24
