DESCRIPTION OF THE DEVICE
Front
1
1
Scanner
Rear
No. 51786200 EAN 4026397708127
∙
T =45°C
a
T =65°C
c
Steinigke Showtechnic GmbH Andreas-Bauer-Str. 5
·
97297 Waldbüttelbrunn Germa
ny
·
www.steini ke.de
g
3
Fuse holder
4
P-Con power in
5
P-Con power out
6
DMX output
7
DMX input
8
USB port for QuickDMX wireless receiver
9
Potentiometer for microphone sensitivity
10
Microphone
11
OLED display
3
4
5
6
7
8
IN
OUT
OUT
IN
T
3.15
A/250V
100-240V 50/60Hz
~
2 1 5W
SAFETY
LED Twin Scan Bar
EYELET
No. 51786200 EAN 4026397708127
∙
12
2
IR
2
Infrared sensor for the remote control
9
10
11
CONTROL
MICROPHONE
SENSITIVITY
MIC
BRIGHTNESS
IR
MENU
UP
13 14 15 16 17 18
12
Safety eyelet
13
Potentiometer for brightness
14
Infrared sensor for the remote control
15
MENU button
16
UP button
17
DOWN button
18
ENTER button
27/44
DOWN ENTER
00141601.DOCX, Version 1.0
