If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.
DESCRIPTION OF THE DEVICE
Features
Slimline LED-Spot with 3 W TCL/3 W BCL
DMX512 control possible via any commercial DMX controller (occupies max.9 channels) • 5, 6, 7 or 9 DMX
channels selectable for numerous applications • Sound-control via built-in microphone • Equipped with 3in1
tricolor LEDs (RGB) as well as 2in1 bicolor LEDs (white/amber) for homogeneous light output • Flat housing
form requires minimal space when rigging • Second mounting bracket for safe standing installation •
Comfortable Addressing and setting via control panel with LCD display and four operating buttons •
Functions: Static colors, RGB color blend, internal programs, dimmer, strobe, sound-control, sensitivity •
Further display settings: display on or off, display inverted, default settings • Master/Slave for parallel
operation of several devices • Feed-through output allows to power another device • After every 8 devices
the fixtures must have a renewed connection with the power mains • Locking possibility at the mounting
bracket • Ready for connection via included IEC power cord with safety plug
Overview
INSTALLATION
The device can be installed on the ground or on the wall or ceiling.
Overhead rigging
Please consider the EN 60598-2-17and the respective national standards during the installation!
The installation must only be carried out by an authorized dealer!
DANGER TO LIFE!
20/30
(1) LED Display
(2) Attachment
eyelet
safety rope
(3) DMX-In socket
(4) DMX-Out socket
(5) Programming buttons
(6) IEC output socket
(7) Power supply
(8) Fuseholder
00064374.DOC, Version 1.0
