( DK )
CE
KONFORMITETSERKLÆRING
Vi erklærer at under almindeligt ansvar, at dette
FKS-210
er i overenstemmelse med følgende
normer eller normative dokumenter
EN60745-1, EN60745-2-5,
EN55014-1, EN-55014-2,
EN61000-3-2, EN61000-3-3,
i henhold til bestemmelserne i direktiverne:
98/37/EC, 89/336/EEC,
2002/95/EC, 2002/96/EC, 2006/95/EC
01-08-2007
ZWOLLE NL
J.A. Bakker - van Ingen
J. Lodewijk
CEO Ferm BV
Quality Manager Ferm Global
Det er vores hensigt til stadighed at forbedre vores
produkter, og vi forbeholder os derfor til enhver tid
retten til at ændre produktspecifikationerne uden
forudgående varsel.
Lingenstraat 6
Ferm BV •
• 8028 PM Zwolle
Holland
52
-
Make sure the blade is secure.
-
Use this circular saw to saw only wood, wood-
like products.
2. Do not use circular saw blades wich are deformed or
damaged.
3. Do not use HSS blades.
4. Only use blades meeting the required dimensions, as
well as data and descriptions;
Never apply any blades of which the thickness is
greater than that of the riving knife.
5. Do not stop the blade of a circular saw by pressing
the blade from the side.
6. Check that the blade guard can freely move and fully
closes.
7. Never lock-up the guard in the open position.
8. Never put sideward pressure on the blade. This may
cause the blade to break.
9. Be careful when cutting wood with knots, nails or
cracks in it and/or dirt on it, as these can cause the
blade to get stuck.
10. Never leave the circular saw unattended.
11. Use this circular saw to saw only wood or wood-like
products.
USING THE MACHINE:
1. Use clamps or a vice to hold the work.
2. Never remove wood chips and saw dust that is close
to the saw blade with your hands. If there are small
pieces of wood left between the fixed and the
movable parts, the circular saw will have to be
stopped. The plug needs to be removed from the
socket, before any left piece can be removed.
3. Check that the blade is suitable for the spindle speed
of the circular saw. Do not attempt to cut before the
circular saw has reached full speed. Make sure the
circular saw runs without load (i.e. is not in contact
with the work) when you switch it on. The circular
saw must have reached its full speed first.
4. Never cut wood that is thicker than the depth of the
saw blade.
5. When cutting in wooden walls or floors, check there
is no wiring or piping where you intend to cut.
6. Switch off the tool and wait until the blade has
stopped completely before moving the saw away
from the work or putting it down. Hearing
protection should be worn when using circular saw.
SWITCH OFF THE MACHINE IMMEDIATELY
WHEN YOU DISCOVER:
1. A defective mains plug or mains lead;
2. A defective switch.
3. Overheating of the circular saw.
4. Smoke or odeur caused by scorched insulation.
3. ASSEMBLY AND ADJUSTING
INSTRUCTIONS
Before adjusting the saw, make sure the plug is
removed from the socket.
SETTING THE SAWING ANGLE (BEVEL)
Fig. B.
-
Loosen the handle (1) that sets the sawing angle.
-
Rotate the soleplate to the correct position (0° -
Ferm
Ferm
45°), and retighten the handle. The sawing angle
(bevel) can be read on the protractor (2).
FITTING THE RIP FENCE
Fig. B.
-
Loosen the knob (3) that clamps the rip fence.
-
Slide the rip fence into the special slot(6) in the sole
plate.
-
Set the correct cut width and retighten the knob (3).
SETTING THE CUT DEPTH
Fig. C.
-
Loosen the handle (1) that sets the sawing depth.
-
Move the soleplate (2) downwards.
-
The cutting depth of the saw blade can be read off the
curved scale attached to the upper side of the sole
plate.
-
Retighten the handle (1) once the correct depth is
set.
EXCHANGING OR CLEANING THE SAW BLADE
Fig. D.
-
Use the shaft locking knob (C3) to prevent the shaft
from rotating.
-
Next, loosen the hexagonal bolt (3) in the centre of
the saw blade, using the box spanner.
-
Turn the safety guard to the rear, and hold it there
with the aid of the knob (1).
-
Remove the outside flange and the saw blade, and
clean the saw blade or replace it with a new one.
-
Again place the saw blade back on the shaft. Ensure
that the teeth of the saw blade are pointing in the
same direction as the riving knife (4).
-
Allow the safety guard to return over the saw blade
by releasing the knob (1).
-
Press the shaft locking knob (C3) back in, refit the
outside flange (5) and tighten the hexagon bolt (3)
firmly, once more.
RENEWING AND REPLACING THE CARBON
BRUSHES
Fig. E.
-
Remove the rear protective cover (no. 1) from the
motor casing, after first loosening the two Phillips
screws.
-
Loosen the screw of the carbon brush holder.
-
Withdraw the carbon brush holder from the casing,
and remove the old carbon brush.
-
Fit the new carbon brush into the holder, and return
the holder to its location in the casing.
-
Re-tighten the screw in the carbon brush holder.
-
Replace both carbon brushes at the same time, and
never mix old and new brushes in this tool.
-
Replace the rear protective cover (no. 1) on the
motor casing, and tighten the two Phillips screws.
Frequent use will cause the carbon brushes to wear
down. Regular inspection, after every 30 hours of
use, is essential. If the brushes have worn down to
less than 4 mm, replace.
