TECHNICAL DATA

GENERAL FEATURES
Material
Display
Connectors
Input data
Output data
Degree of protection
(according to IEC 60529)
ENVIRONMENTAL FEATURES
Operating temperature
Storage temperature
ELECTRICAL FEATURES
Rated voltage
Operating voltage
Current consumption
Absorption (LEN)
Aluminum case
PBT and mineral glass front screen
IPS TFT 4.3" – 480x272
Full 24 bit / 16 mio. colors
•
1x Molex MX150 12 pin
•
1x NMEA 2000 Micro-C M12 5 pin
•
1x AMP SuperSeal 1.5 Series (EasyLink)
•
CAN (NMEA 2000 and SAE J1939)
•
2x resistive inputs (0-400 Ω)
•
2x capacitive inputs (4-20mA)
•
1x frequency inputs (0-4 kHz)
•
NMEA 2000
•
EasyLink
•
Alarm outputs (500mA max)
IPX7
From -25 to +70 °C
From -40 to +85 °C
12/24 V
9–32 V
< 900 mA @ 12 V (display only)
100mA for each EasyLink satellite gauge
2
TECHNICAL DATA
A2C15587600
