4. CALIBRATE THE SENSOR
Every sensor type has a standard calibration
(see "Default supported calibrations").
Veratron sensors are by default supported.
It is however possible, for some sensors, to
calibrate the sensor through a calibration
wizard (see next chapters).
Every sensor type can be always calibrated
via the PC-based veratron Configuration
Tool (see "Sensor calibration with Veratron
Configuration Tool").
DEFAULT CALIBRATIONS
Sensor Type
Fuel
Fresh Water
Waste Water
Trim
Rudder
Eng. Coolant Temp
Eng. Oil Temp
Eng. Oil Pressure
Boost Press
Calibration
240-33 Ω
3-180 Ω
2-90 Ω
3-180 Ω (resistive inputs)
4–20mA (capacitive inputs)
3-180 Ω (resistive inputs)
4–20mA (capacitive inputs)
10-167 Ω
10-180 Ω
291-22 Ω
197-11 Ω
10-184 Ω
10-184 Ω
SENSOR CONFIGURATIONS
