DATA SCREENS

Data screens show the data received from the various sources. The display can store up to 10 data screens.
By default, four screens are displayed, configured to display the previously selected engine, and one page for
remote management of a MediaBox multimedia device.
The ALARMS page appears at the end of the data pages if there are active alarms.
SCREENS SCROLLING
To scroll pages, press the UP or DOWN buttons or scroll the touch screen horizontally with your finger. To
add/delete/edit pages, see "Data page configuration".
SCREEN LAYOUTS
Every screen contains some common elements, which are always displayed independently of the screen layout
which is chosen.
The screen content [D] depends on the screen configuration that the user has selected for a specific screen
(see "Screen Configuration").
Part Description
GPS signal availability (not
A
included)
Screen title or additional data
B
field (fixed)
C GPS time (if received)
D Screen content
E Screen number
