CONFIGURE A LOCAL ALARM
1. Press the MENU button and select ALARMS > CONFIGURE ALARMS
2. Select one of the supported alarms
3. Activate it by selecting Active > Yes, the alarm parameters will appear
4. Then select and edit the threshold(s) and enable/disable the buzzer
Setting
Depth shallow
Depth navigation
Wind
Battery voltage
Battery Temperature
Battery Charge
Engine water temp
Engine oil temp
Engine oil pressure
Exhaust Gas Temp
Fuel
Fresh water
Waste water
Local alarm input
Min RPM
Description
Shallow water alarm.
Depth navigation alarms.
Deep water alarm (e.g., a value near
the maximum value measurable by
the sensor) and safety depth
minimum threshold.
High wind speed.
Low battery voltage.
High battery temperature.
Low battery state of charge.
High engine coolant temperature.
High engine oil temperature.
Low engine oil pressure.
High EGT.
Low fuel level.
Low fresh water level.
High waste water level.
External digital switch (low active
alarm).
Refer to "Connections diagram".
RPM minimum threshold to trigger
engine-related alarms.
Possible NMEA 2000
values output
0 – 9.9 m (2m)
0 – 99.9 m
(50m, 5m)
0 – 99.9 km/h
(39.9km/h)
0 – 32.9 V
(10.8V)
0 – 99 °C
(50°C)
0 – 99 %
(50%)
0 – 139 °C
(110°C)
0 – 149 °C
(120°C)
0 – 9.9 bar
(0.5bar)
0 – 899 °C
(500°C)
0 – 99 %
(20%)
0 – 99 %
(20%)
0 – 99 %
(80%)
0 – 990 RPM
(300RPM)
ALARMS
No
No
No
Yes
No
No
Yes
Yes
Yes
Yes
No
No
No
No
-
