Veratron OCEANLINK 4.3 Benutzerhandbuch Seite 19

WIND screen
Dedicated screen layout for navigation with graphical
representation of both apparent and true wind data.
Six customizable data fields are designed aside.
INTELLIGENT BATTERY MONITOR screen
Dedicated screen for battery monitoring including
extensive battery information coming from the
Intelligent Battery Sensor (IBS).
SUPPORTED DATA
Icon Data
Engine rpm
Engine trim
Engine boost pressure
Engine coolant temp
Battery voltage
Fuel consumption (Tank: 1-4)
Fuel rate
PITCH AND ROLL screen
Monitors your boat inclination, with the information
retrieved from a connected NavSensor, for example.
Input
NMEA SAE
Analogue
2000 J1939
x x
x -
x x
x x
x x
x x
x -
Output
NMEA
EasyLink
2000
x x x
x x x
x x x
x x x
x x x
x x x
- - -
DATA SCREENS
Unit
rpm
%
bar / psi / kPa
°C / °F
V
%
gal/h or l/h
A2C15587600
