Prowirl 72F Dualsens-Ausführung nach JIS B2238
DN Druckstufe
DIN/JIS
40 Schedule 40
Schedule 80
Schedule 40
50 Schedule 80
Schedule 40
80 Schedule 80
Schedule 40
100 Schedule 80
150 Schedule 40
Schedule 80
d D
[mm] [mm]
20K 41,2 140,0
20K 38,1 140,0
40K 38,1 160,0
10K 52,7 155,0
20K 52,7 155,0
10K 49,2 155,0
20K 49,2 155,0
40K 49,2 165,0
10K 78,1 185,0
20K 78,1 200,0
10K 73,7 185,0
20K 73,7 200,0
40K 73,7 210,0
10K 102,3 210,0
20K 102,3 225,0
10K 97,0 210,0
20K 97,0 225,0
40K 97,0 240,0
10K 151,0 280,0
20K 151,0 305,0
10K 146,3 280,0
20K 146,3 305,0
40K 146,6 325,0
Proline Prowirl 72F, 72W, 73F, 73W
H L X
[mm] [mm] [mm]
303 200 31
310 200 33
323 200 39
335 250 49
359 300 64
Endress+Hauser
Gewicht
[kg]
16
17
18
25
27
42
49
80
