Operating controls and appliance parts
(1)
Baumwolle
Mix
Synthetik
Feinwäsche
Wolle
Jeans
Sportwäsche
Babybekleidung
Trommelreinigung
(1) Cycle selector
(2) LED "Current washing water
temperature"
(3) LED "Current spin speed"
(4)
LED "Start time preselection active"
(5)
LED "Button lock active"
(6)
LED "Appliance lid locked"
(7) LED "Pre-wash selected"
LED "Extra rinse selected"
(8)
button to switch the appliance on or
off
(9)
button for starting, interrupting,
cancelling and recommencing a cycle
(10) "Function" button to select "
wash" and/or " Extra rinse"
(11) "Start time preselection" button to start
the cycle at a later time
Operating controls and appliance parts
(2) (3)
Express15'
Schnell 45'
ECO 40-60
Intensiv
20°C
Spülen
Schleudern
Temp.
(13) (12)
(12) "Rpm
spin speed and to mute beeping
(13) "Temp" button to select another
washing water temperature
(14) Appliance lid with handle
(15) Dispenser with three compartments
(16) Washing drum
(17) Shutter of the lint trap
(18) Connection for water inlet hose
(19) Water outlet hose
(20) Screw feet
(21) Mains connection cable with mains
plug (not shown)
Pre-
(22) Transport safety devices incl. screws
(4) (6) (7)
(5)
9H
6H
3H
3 Sek. drücken für Signal
Funktion
(11) (10)
" button to select a different
Page EN-9
(8)
Ein/Aus
Start/Pause
(9)
