Note!
For workplace safety, protect from tipping or shifting by
securing the saw with screws or bolts to the floor.

Initial operation

Before commissioning observe the safety notes.
• All safety and auxiliary installations must be fitted.
• Check the rocker inlet (16) for wear and replace it
if necessary.
• Check the rocker (2) that it returns to its home posi-
tion autonomously.
• Check the saw blade for perfect fitting and correct
direction of rotation.
• Changeover, setting, measuring and cleaning op-
erations are only to be conducted with the motor
switched off. Pull the mains plug and wait for the
rotating tool to come to halt.
• The saw is constructed solely for the cross cutting
of firewood.
• Regardless of the diameter of the wood only one
work piece is to be put on the rocker.
• ATTENTION! Do not saw faggots or multiple pieces
at once.
• Put curved wood on the rocker in such a way that the
curved-out side is directed to the saw blade.
• Ensure the machine is securely placed on solid
ground.

Operation notes

ON/OFF switch (Fig. 12)
The machine is equipped with a safety switch preventing
the machine from being activated after a voltage drop.
Turning on
Press green button I
Turning off
Press red button O
Sawing
1. Turn on the machine.
2. Wait until the saw blade has reached full speed.
3. Put the wood on the rocker.
4. Take hold of both handle bars of the rocker with both
hands and lead it evenly to the saw blade; thus the
saw blade is revealed.
5. Push the rocker evenly to ensure the engine speed
does not drop.
6. Remove the sawn wood from the rocker before put-
ting on the next piece.
