• Use only original accessories, wearing or replace-
ment parts. You can find replacement parts at your
Scheppach dealer.
• When ordering, include our item number and the
type and year of construction of the machine.
HS510
Technical data
Dimensions L x
W x H
ø Saw blade
Weight
Working tips
ø wood min./max.
Length of wood
min/max
Drive
Motor V/Hz
Performance
input P1
Output power P2
Operation mode
Rated idling
revolution speed
Nominal current
Undervoltage
cutback
Subject to technical changes!
Noise characteristic values
Measurement conditions
The values stated are emission values and are therefore
not necessarily safe operating values. Although there is
a correlation between emission and immission levels,
you cannot reliably deduce from this whether additional
safety measures are required or not. Factors which can
influence the immission level currently at the workstation
comprise the duration of the effects, the characteristics
of the work room, other sources of noise etc., for exam-
ple, the number of machines and adjacent operations.
The permissible values per workstation can also vary
from country to country. This information should never-
theless enable the user to make a better estimation of
dangers and risks.
Sound level at the workplace in dB
L = 105 dB (A); L = 91 dB(A)
WA pA
A measurement uncertainty allowance K = 2 dB applies
to the mentioned emission values.
790 x 740 x 960 mm
500/30/3,6/2,6 Z40
67 kg
ca. 3/17 cm
25/100 cm
220–240 V/50 Hz
2600 W
2056 W
S6/40 %
2800 rpm
11,32 A
yes
