4 Modbus addresses
Data type/
Address bit number
0x0024 INT
Bit 0
Bit 1
0x0025 INT
Bit 0 + Bit 8
Bit 1 + Bit 9
Bit 2 + Bit 10
Bit 3 + Bit 11
0x0026 FLOAT
0x0028 FLOAT
0x002A INT
0x002B FLOAT
0x002D FLOAT
0x002F FLOAT
0x0031 FLOAT
0x0033 FLOAT
0x0035 FLOAT
0x0037 FLOAT
0x0039 FLOAT
0x003B FLOAT
0x003D FLOAT
0x003F FLOAT
0x0041 FLOAT
0x0043 INT
0x0044 INT
0x0046 INT
0x0047 LONG
0x0049 LONG
0x004B INT
Bit 1
Bit 5
Bit 6
Bit 15
4.2

Set point values

Address
0x3100
0x3102
20 | nVent.com
Access
R/O
R/W
R/O
R/O
R/O
R/O
R/O
R/O
R/O
R/O
R/O
R/W
R/O
R/O
R/O
R/O
R/O
R/O
R/O
R/O
R/O
R/O
R/O
Data type/
bit number Access
FLOAT R/W
FLOAT R/W
Signal designation
Limit comparators 1...2
Limit comparator 1 (= 0x0001)
Limit comparator 2 (= 0x0002)
Control of the binary outputs (individual)
Output K1 (= 0x0101)
Output K2 (= 0x0202)
Output K3 (= 0x0404)
Output K4 (= 0x0808)
Analog input [mV]
Internal Pt100 [Ohm]
Sampling cycle time
Analog input [displayed value]
Internal analog value 1
Internal analog value 2
Controller, ramp limit value
Controller, actual value, FILTERED
Controller, actual value, UNFILTERED
Controller set point value
Controller, output value display
Controller, output value, HEATING
Controller, output value, COOLING
Controller, control difference
Controller, control deviation
Controller, switching state, HEATING
Controller, switching state, COOLING
Output value, manual mode
Timer run time
Residual timer time
Timer status
Timer stopped (= 0x0002)
Timer runs (= 0x0020)
Timer end (= 0x0040)
Timer signal (= 0x8000)
Signal designation
Set point value W1
Set point value W2
