2 Protocol description
2.6.3 Write n words
This function is used to write n (n ≤ 32) words starting from a specific address.
Instruction
Slave
address
1 byte
Response
Slave
address
1 byte
Example
Writing the W1 and W2 set point values (2 words each)
Word address = 0x3100 (W1 set point value)
Instruction:
01
Response:
01 10
12 | nVent.com
Function Address
0x10 first word
1 byte 2 byte
Function
0x10
1 byte
10 3100 0004
3100 0004 CF36
Number
of words Number of
(max. 32) words
2 byte 1 byte
Address Number of
first word words
2 byte 2 byte
08 0000 41C8
Set point value
W1
(25.0)
Word Checksum
value(s) CRC16
x byte 2 byte
Checksum
CRC16
2 byte
0000 4120 2A42
Set point value
W2
(10.0)
