Modbus addresses
Data type, type of access
The following tables contain specifications of all process and device data including
their addresses, data type and type of access.
Meaning:
R/O
W/O
R/W
INT
Bit x
LONG
FLOAT
TEXT4
G
Write operations to R/W parameters result in them being saved to the EEPROM. These
memory modules only have a limited number of write cycles (approx. 10000). For this
reason, this function can be switched off in the case of frequent programming. The
parameter values are then only saved in the volatile memory (RAM) and will be lost after a
supply failure.
ð S etup program (undocumented parameters - > Bit parameters
- > Set parameter 2)
4.1
Process data
Data type/
Address
bit number
0x001F
INT
Bit 12
Bit 13
0x0020
INT
Bit 12
Bit 15
0x0021
INT
Bit 0
Bit 1
Bit 2
Bit 3
0x0023
INT
Bit 0
Bit 1
Read only access
Write only access
Read/write access
Integer (8 or 16 bit)
Bit No. x (bit 0 is always the bit with the lowest value)
Long integer (4 byte)
Float value (4 bytes) as per IEEE 754
Text 4 characters
Access
R/O
R/O
R/O
R/O
Signal designation
Internal binary values
Binary value L1 (= 0x1000)
Binary value L2 (= 0x2000)
Controller status
Manual mode active (=0x1000)
Self-optimization active (=0x8000)
Binary outputs 1...4
(Switching states 0 = off / 1 = on)
Output K1: Relay (= 0x0001)
Output K2: Relay (= 0x0002)
Output K3: Logic (= 0x0004)
Output K4: Relay (= 0x0008)
Binary inputs 1 and 2
(Switching states 0 = open / 1 = closed)
Input 1 (= 0x0001)
Input 2 (= 0x0002)
