EN
WARNING!
The actual vibration and noise level when
using tools may differ from the specified
maximum value, depending on how the
tool is used and the material. It is therefore
necessary to determine which safety
precautions are required to protect the user,
based on an estimate of exposure in actual
operating conditions (taking into account all
stages of the work cycle, e.g. the time when
the tool is switched off and when it is idling,
in addition to the start-up time).
DESCRIPTION
1. Table
2. Vice
3. Chuck cover
4. Power switch
5. Belt cover
6. Power switch for laser
7. Motor
8. Laser
9. Handle
10. Pillar
11. Table holder
12. Clamping handle for table holder/height
adjustment

13. Base plate

14. Depth stop
15. Chuck
16. Mounting hole
FIG. 1
FIG. 2
ASSEMBLY
MOUNTING OF COLUMN ON
BASE PLATE
FIG. 3
1. Put the base plate (13) on the floor, or on
a work bench.
54
2. Put the column (10) on the base plate (13)
and align the screw holes in the column
flange and base plate.
3. Screw the column (10) to the base plate
(13) with three screws (L) and washers
(G + H).
FITTING THE TABLE ON
THE COLUMN
Slide the table holder and table (1) on to the
column (10). Lock the table in the required
position with the clamping handle (12).
FIG. 4
FITTING THE MACHINE HEAD ON
THE COLUMN
Put the machine head (A) with the belt cover
(5) and motor (7) on the column (10) and
tighten with the hex screws (M).
FIG. 5
Fitting the feeder handle on
the feed shaft
Screw the handles (9) in the threaded holes in
the feed shaft.
FIG. 6
FITTING THE CHUCK ON
THE SPINDLE
NOTE:
All non surface treated metal surfaces are
greased to prevent corrosion. Before fitting
the chuck (15) on the spindle (N) the contact
surfaces of both parts must be washed clean
of grease with eco-friendly degreasing agent
for the transmission of power between the
spindle and chuck to function.
• Clean the conical hole in the chuck (15)
and the conical surface on the spindle (N)
with a clean cloth. Check that both
surfaces are clean and free from foreign
particles. The slightest amount of dirt will
prevent the correct alignment between
