Nussbaum SPRINTER MOBIL 2500 Betriebsanleitung Und Prüfbuch Seite 35

.7 990133 + 990181 CONTACT ELEMENT - NO,
CONTACT ELEMENT - NC
.8 990841 POWER CONTACTOR
.9 990661 CLAMP (SAFETY) DISCONNECT
.10 990183 SERIES CLAMP GRAY
70.xx Hydraulics
1
2*
7
3
.1 600499 DIRECTIONAL SEATED VALVE
.2 159604 CHECK VALVE
.3 232HL01056-SH CONTROL BLOCK
.4 982186 OIL DIPSTICK
20110005 OPI 08.12.2015
All manuals and user guides at all-guides.com
SPRINTER MOBIL - HYMAX PRO
.11 990578 PROTECTIVE EARTH CLAMP
.12 995561 CONNECTION PLATE YELLOW
.13 232HL01067-1 HANDLE
.5 992463 UNDER OIL MOTOR
.6 160544 MECHANICAL PUMP
.7 600161 PRV - PRESSURE RELIEF VALVE
* = not visible
1
4
5 6
35
