30.xx Scissors
16
5
.1 025SPB06100 EXTERIOR SCISSORS, COMPLETE
.2 025SPB26150 INTERIOR SCISSORS, COMPLETE
.3 025SPB68162 WHEEL AXLE COMPLETE
.4 9125-16ZN CYLINDER LEVER BOLT
.5 025SPB02026 CYLINDER LEVER BOLT
.6 9PAP202320P10 DU JACK
.7 9PAP303430P10 DU JACK
.8 025SPB06037 MIDDLE JOINT BOLT
.9 025SPB06021 SLIDING PIECE TOP
.10 9125M30ZN WASHER
20110005 OPI 08.12.2015
All manuals and user guides at all-guides.com
12 4 9
3
SPRINTER MOBIL - HYMAX PRO
6
8 14 7 10
1 2
.11 9125_6_4ZN
.12 9934M16ZN
.13 435H06016-1
.14 91481-6X50
.15 9912M06X012ZN
.16 9Z912M16X045ZN CYLINDER SCREW
11
15
13
20150413 025spb06110_et
WASHER
HEXAGONAL NUT
SAFETY PLATE
FRICTION BOLT
CYLINDER SCREW
