Attention! Unplug the mains plug.
1 Open the cover (E).
2 Open the belt clamping lever (G).
3 Lift the motor by means of the lever (H).
4 Set the belt to level 2.
5 Attention! The belt must be aligned accurately.
6 Clamp the belt and lock it with the clamp lever (G)
7 Rotate the spindle by hand slightly and check the belt
run.
8 Close the cover and lock with the screw.
NOTE: Extremely high belt-tension causes rapid wear of the
belt.
Close the casing and lock into place by turning the screw
1/4 of a revolution to the right. When the cover is closed,
read the adjusted speed from the viewing-window. When
working with highly unbalanced workpieces, select a
speed at least one level lower.
Overload protection Fig.9 (F)
In the event of an overload, the machine switches the
motor off.
Once the motor has cooled down, press the button (F). It
is now possible to start work again.
Driver, Fig. 1.1, B
The driver is used exclusively for work between both
centers.
Face plate, figure 1.1, A
The face plate is used with flat larger tools.
Changing the tensioning tools. Fig. 10
Unfasten the headless set screw on the shaft of the face-
plate.
Rotate manually until the stopper bar snaps into place.
Remove the face-plate from the spindle by rotating it
counter-clockwise.
Changing the carrier Fig. 11
The carrier is located in the cone of the spindle and is
released by slightly knocking the stopper bar.
Attention!! When exchanging the tools, always clean the
cone from dust and shavings.
Tailstock, figure 12
• Once the eccentric clamp has been loosened, the tail-
stock can be moved over the entire length of the bed
and can be secured at any distance from the head-
stock.
• To insert a workpiece between the centers, loosen the
binder, turn the sleeve approx. 20 mm outward and
clamp.
• Slide the tailstock to the workpiece and place the tail-
stock center into the sunken point in the center of the
workpiece.
• Screw out the tailstock sleeve until the tailstock center
rests securely in the wood. Retighten the binder.
• Turn the workpiece to see if it rests securely between
the two centers and can be rotated freely.
Tailstock center replacement, Fig. 12
• Loosen the binder (5).
• Turn tailstock spindle sleeve totally backwards until the
tip can be removed.
All manuals and user guides at all-guides.com
Headstock, Fig. 13
The headstock is moveable and can be clamped into any
position with the lever 1C.
By moving the headstock by 180°, work pieces with a di-
ameter of up to 500 mm can be worked with the exten-
sion console (accessory).
Tool holder, Fig. 14
• The tool holder both insures safe use of wood turn-
• Place the tool holder at a distance of 1 – 3 mm from the
• Set the tool holder ca. 3 mm above the axis of the
• Once the eccentric clamp has been loosened, the hold-
• To work with a plane surface, turn the tool holder 90º
• If the headstock is swivelled, then the tool rest with the
• Therefore it is inserted from the left of the headstock
Use of wood turning tools, Fig. 15
Examples of how to use the tools when working with
the most frequent forms. Once the machine has been
plugged in, it is ready to be used. Observe the operating
instructions in „Electrical connection".
A perfect and sharp wood turner tool is a precondi-
tion for professional wood-turning.
Selection of materials
• Wood to be turned must be of good quality and with-
• Workpieces that have been glued together should only
Note: Beginners should first master fundamental skills by
working exclusively with solid material.
Preparation of the materials
• To turn long pieces of wood, the material must be cut
• To turn a cross-arm, the material must be cut to size in
ing tools and at the same time serves as a support
for the hand.
The height of the tool holder can be adjusted once the
binder has been loosened. To turn further, pull in the
direction indicated by the arrow.
workpiece. Check the adjustment in addition to rotating
the workpiece by hand.
workpiece.
Check the adjustment once again by rotating the work-
piece by hand.
er console can be moved along the entire length of
the bed and in the direction perpendicular to the work-
piece. Furthermore, the holder console can be tilted
over approx. 45º to either side.
and place up against the surface to be worked. De-
pending on the wood turning tool, place the tool holder
up to 6 mm underneath the axis of the workpiece.
extension is to be used (Fig. 11).
so that larger discs can be processed.
Operations
out imperfections such as fissures against the grain,
a marred surface, or knots. Faulty wood tends to split
and becomes a risk for both the operator and the ma-
chine.
be processed by experienced craftsmen. Because the
workpiece can explode as a result of developing cen-
trifugal force, turning such wood demands careful glu-
ing without weak points.
into a square form beforehand.
its natural state as well. Saw out the rough form with a
band saw. An octagonal form is recommended for the
material so that vibrations are reduced.
