Inserting/Removing­the Battery; Switching­on/Off; Checking­the­battery­charge Level; Recharging The Battery - Parkside PKGA 20-Li C2 Originalbetriebsanleitung

GB IE
Removing appliance attachment
1.­ Push­the­unlocking­lever­(5)­into­posi-
­as­far­as­the­stop­and­then­
tion
hold­it­in­this­position.
2.­ Pull­the­unlocked­appliance­attachment­
off­(4/16/22/26).
Fitting appliance attachment
3.­ Push­the­appliance­attachment­
(4/16/22/26)­along­the­guide­rail­
into­the­motor­unit­(6).
4.­ Allow­the­unlocking­lever­(5)­to­slide­
back­into­position­
5.­ Check­that­the­appliance­attachment­is­
secure­by­pulling­on­it.
Inserting/removing­
the battery
1.­ To­remove­the­battery­(9)­from­the­de-
vice,­press­both­release­buttons­(9b)­on­
the­battery­and­pull­the­battery­out.
2.­ To­insert­the­battery­(9),­push­the­bat-
tery along the guide rail into the de-
vice.­You­will­hear­it­click­into­place.
Only insert the rechargeable
battery once the device is
completely assembled. Risk
of injury!
Switching­on/off
1. Switching on:­Press­the­on/off­switch­
(10).
­ By­using­the­on/off­switch­(10)­you­
can­progressively­control­the­speed.­
­ Gentle­pressure:­low­speed
­ Increase­pressure:­higher­speed.
2. Switching off: Release­the­on/off­
switch­(10).
­ If­you­place­the­direction­switch­
(7)­in­the­middle­position,­the­device­is­
secured against being switched on.
36
.
Checking­the­battery­
charge level
The­battery's­(9)­charge­level­is­indicated­
by­the­charge­state­indicator­(9a).
• The charge level of the battery is
indicated by illumination of the corre-
sponding­LED­lights­while­the­device­is­
in­operation.­Press­and­hold­the­power­
button to view.
red-yellow-green => Battery fully charged
red and yellow => Battery half charged
red
=> Battery needs
­ Charge­the­battery­(9)­when­only­
the­red­LED­on­the­level­indicator­is­
illuminated.

Recharging the battery

Allow a hot battery to cool before
charging.
­ Only­charge­the­battery­(9)­when­
the­red­LED­on­the­charge­status­
indicator­(9a)­is­on.
1.­ Remove­the­battery­(9)­from­the­appli-
ance,­as­necessary­(see­„Removing/
inserting­the­battery").
2.­ Insert­the­battery­(9)­in­the­charging­
compartment­of­the­battery­charger­
(14).­
3.­ Plug­the­battery­charger­(14)­into­a­
mains outlet.
4. When the battery is fully recharged un-
plug­the­battery­charger­(14)­from­the­
mains.
5.­ Remove­the­battery­(9)­from­the­charg-
er­(14).
to be charged
