Endress+Hauser Mycom S CXM 153 Betriebsanleitung Seite 60

Störungsbehebung
NAMUR Fehler- Beschreibung
-Klasse Nr.
Ausfall E034 eingestellter Offsetbe-
reich Sensor 1 verlassen
Ausfall E035 eingestellter Steilheitsbe-
reich Sensor 2 verlassen
Ausfall E036 eingestellter Nullpunktbe-
reich Sensor 2 verlassen
Ausfall E037 eingestellter Offsetbe-
reich Sensor 2 verlassen
Wartung E038 Delta-Schwelle über-
schritten
Wartung E040 SCC / Elektrodenzustand
Sensor 1 schlecht
Wartung E041 SCC / Elektrodenzustand
Sensor 2 schlecht
Wartung E043 Pufferdifferenz Kreis 1 zu
gering
Wartung E044 Messwert Kreis 1 nicht
stabil
Ausfall E045 Kalibrierung abgebro-
chen
Wartung E048 Pufferdifferenz Kreis 2 zu
gering
Wartung E049 Messwert Kreis 2 nicht
stabil
Wartung E050 Reiniger fast leer
Wartung E051 Puffer 1 fast leer
Wartung E052 Puffer 2 fast leer
Ausfall E053 Drei-Punkt-Schritt-Regler
Wartung E054 Dosierzeitalarm
Ausfall E055 Anzeigebereich des
Hauptparameters 1 unter-
schritten
Ausfall E056 Anzeigebereich des
Hauptparameters 2 unter-
schritten
Ausfall E057 Anzeigebereich des
Hauptparameters 1 über-
schritten
Ausfall E058 Anzeigebereich des
Hauptparameters 2 über-
schritten
Ausfall E059 Temperaturbereich 1
unterschritten
Ausfall E060 Temperaturbereich 2
unterschritten
60
DIAGNOSIS
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
20 00 00 80 - DIA_MEASUREMENT
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
00 20 00 80 - DIA_MAINTENANCE
00 00 00 80 - EXTENSION_AVAILABLE 00 80 00 00 00 00 BAD
00 20 00 80 - DIA_MAINTENANCE
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
20 00 00 80 - DIA_MEASUREMENT
Mycom CXM 153 PROFIBUS-PA
DIAGNOSIS_ Messwert-Status
EXTENSION
Quality
00 20 00 00 00 00 BAD
00 20 00 00 00 00 BAD
00 20 00 00 00 00 BAD
00 20 00 00 00 00 BAD
00 00 00 01 00 00 UNCERTAIN non-specific
00 00 00 02 00 00 UNCERTAIN sensor
00 00 00 02 00 00 UNCERTAIN sensor
00 00 00 04 00 00 UNCERTAIN configuration
00 00 00 08 00 00 UNCERTAIN configuration
00 40 00 00 00 00 BAD
00 00 00 04 00 00 UNCERTAIN configuration
00 00 00 08 00 00 UNCERTAIN configuration
00 00 00 10 00 00 GOOD
00 00 00 10 00 00 GOOD
00 00 00 10 00 00 GOOD
00 00 00 20 00 00 UNCERTAIN configuration
00 00 01 00 00 00 UNCERTAIN sensor
00 00 01 00 00 00 UNCERTAIN sensor
00 00 01 00 00 00 UNCERTAIN sensor
00 00 01 00 00 00 UNCERTAIN sensor
00 00 02 00 00 00 UNCERTAIN sensor
00 00 02 00 00 00 UNCERTAIN sensor
Sub-Status
configuration 04
error
configuration 04
error
configuration 04
error
configuration 04
error
40
50
conversion not
accurate
50
conversion not
accurate
5C
error
5C
error
configuration 04
error
5C
error
5C
error
maintenance A4
required
maintenance A4
required
maintenance A4
required
non-specific 00
5C
error
50
conversion not
accurate
50
conversion not
accurate
50
conversion not
accurate
50
conversion not
accurate
50
conversion not
accurate
50
conversion not
accurate
