Mycom CXM 153 PROFIBUS-PA
Byte
Byte
Datenblöcke
Lange
Länge
(Eingabe)
(Ausgabe)
0 ... 4
–
Analog Input Block 1
(pH Kanal 1)
5 ... 9
–
Analog Input Block 2
(Temperatur
Kanal 1)
10 ... 14
–
Analog Input Block 3
(pH Kanal 2)
15 ... 19
–
Analog Input Block 4
(Temperatur
Kanal 2)
–
–
Platzhalter
0 ... 1
Control CPM (SP_D) aktiv
–
–
Platzhalter
Vollkonfiguration Mycom S CPM 153 ohne TopCal S
Ersetzen von Messgrößen durch Platzhalter (Free Place) mittels der herstellerspezifi-
schen GSD-Datei
Status
Zugriff GSD
aktiv
read
aktiv
read
aktiv
read
aktiv
read
inaktiv
–
write
inaktiv
–
GSD
Blockbezeichnung
Erweiterte
Blockkennung
Main Process Value
0x42, 0x84, 0x08, 0x05
Main Temperature
0x42, 0x84, 0x08, 0x05
2nd Process Value
0x42, 0x84, 0x08, 0x05
2nd Temperature
0x42, 0x84, 0x08, 0x05
Free Place
0x00
Control CPM
0x82, 0x81, 0x05, 0x05
Free Place
0x00
Bedienung
GSD
Standard-
Blockkennung
0x94
0x94
0x94
0x94
0x00
0xA1
0x00
21
