Bedienung
Byte
Byte
Datenblöcke
Lange
Länge
(Eingabe)
(Ausgabe)
0 ... 4
–
Analog Input Block 1
(Lf Kanal 1)
–
–
Platzhalter
–
–
Platzhalter
–
–
Platzhalter
0 ... 1
Control CLM (SP_D)
26
Teilkonfiguration Mycom S CLM 153
Ersetzen von Messgrößen durch Platzhalter (Free Place) mittels der herstellerspezifi-
schen GSD-Datei
Status
Zugriff GSD
aktiv
read
inaktiv
–
inaktiv
–
inaktiv
–
aktiv
write
Mit dieser Konfiguration wird nur der Hauptmesswert (Lf Kanal 1) und die herstellerspe-
zifische Steuerung des Mycom S CLM 153 (Control CLM) aktiviert.
GSD
Blockbezeichnung
Erweiterte
Blockkennung
Main Process Value
0x42, 0x84, 0x08, 0x05
Free Place
0x00
Free Place
0x00
Free Place
0x00
Control CLM
0x82, 0x81, 0x05, 0x05
Mycom CXM 153 PROFIBUS-PA
GSD
Standard-
Blockkennung
0x94
0x00
0x00
0x00
0xA1
