Unit Parts

NOTE: The installation must be performed in accordance with the requirement of local and
national standards. The installation may be slightly different in different areas.
1
2
4
5
（1）
Wall Mounting Plate
1
2
Front Panel
Power Cable (Some Units)
3
Louver
4
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor
unit may be slightly different. The actual shape shall prevail.
3
A
6
7
8
Functional Filter (On Back of
5
Main Filter - Some Units)
6
Drainage Pipe
7
Signal Cable
8
Refrigerant Piping
2
4
5
9
10
11
1
Air-break switch
3
A
（2）
Remote Controller
9
Remote controller Holder
10
(Some Units)
Outdoor Unit Power Cable
11
(Some Units)
3
6
7
8
11
