Operation of buttons ON/OFF Button This button turns the air conditioner ON and OFF. MODE Button Press this button to modify the air conditioner mode in a sequence of following: AUTO COOL HEAT NOTE Please do not select HEAT mode if the machine you purchased is cooling only type.
Seite 5
Operation of buttons UP Button( Push this button to increase the indoor temperature setting in 1 C increments to 30 C. DOWN Button( Push this button to decrease the indoor temperature setting in 1 C increments to 17 C. SILENCE/FP Button Active/Disable SILENCE function.
Seite 6
Operation of buttons Swing Button (applicable to RG57A4/BGEF) (not included in this model) Swing Button (applicable to RG57A4/BGEF) Used to stop or start horizontal louver move- ment or set the desired up/down air flow direction. The louver changes 6 degree in angle for each press.
Indicators on LCD Information are displayed when Mode display the remote controller is powered AUTO COOL HEAT Displayed when data transmitted. Displayed when remote controller is ON. Battery display(low battery detection) Not available for this unit Displayed when TIMER ON time is set. Displayed when TIMER OFF time is set.
How to use the buttons Auto operation Ensure the unit is plugged in and power is available. The OPERATION indicator on the display panel of the indoor unit starts flashing. 1. Press the MO D E button to select Auto. 2.
How to use the buttons Dehumidifying oper ation Ensure the unit is plugged in and power is available. The OPERATION indicator on the display panel of the indoor unit starts flashing. 1. Press the MO D E button to select DRY mode. 2.
Timer operation Press the TIMER ON button can set the auto-on time of the unit. Press the TIMER OFF button can set the auto-off time of the unit. T o set the Auto-on time. 1. Press the TIMER ON button. The remote controller shows TIMER ON, the last Auto-on setting time and the signal "H"...
Seite 11
CAUTION When you select the timer operation, the remote controller automatically transmits the timer signal to the indoor unit for the specified time. Therefore, keep the remote controller in a location where it can transmit the signal to the indoor unit properly. The effective operation time set by the remote controller for the timer function is limited to the following settings: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10, 11, 12, 13, 14, 15,16,17, 18, 19, 20,...
Seite 12
TIMER OFF (Auto-off Operation) The TIMER OFF feature is useful when you want the unit to turn off automatically after you go to bed. The air conditioner will stop automatically at the set time. Example: Stop To stop the air conditioner in 10 hours. 1.
Seite 13
TIMER ON TIMER OFF (Off Start Stop operation) This feature is useful when you want to start the air conditioner before you wake up and stop it after you leave the house. Example: Start To start the air conditioner 2 hours after setting, Stop and stop it 5 hours after setting.
Handling the remote controller Location of the remote controller. Use the remote controller within a distance of 8 meters from the appliance, pointing it towards the receiver. Reception is confirmed by a beep. CAUTIONS The air conditioner will not operate if curtains, doors or other materials block the signals from the remote controller to the indoor unit.
Replacing batteries The following cases signify exhausted batteries. Replace old batteries with new ones. Receiving beep is not emitted when a signal is transmitted. Indicator fades away. The remote controller is powed by two dry batteries (R03/LR03X2) housed in the back rear part and protected by a cover.
Seite 16
ΠΕΡΙΕΧΟΜΕΝΑ Χαρακτηριστικά του Ασύρματου Τηλεχειριστηρίου ............3 Λειτουργίες Πλήκτρων ....................... 4 Ενδείξεις στην LCD Οθόνη ....................7 Χρήση των πλήκτρων ......................8 Αυτόματη Λειτουργία ......................8 Λειτουργίες Ψύξης/Θέρμανσης/Ανεμιστήρα ..............8 Λειτουργία Αφύγρανσης ..................... 9 Λειτουργία Timer ....................... 10 Χειρισμός του Ασύρματου Τηλεχειριστηρίου ............... 14 Σημείωση: •...
Λειτουργίες Πλήκτρων Πλήκτρο ON/OFF Με αυτό το πλήκτρο γίνεται η εκκίνηση και η διακοπή της λειτουργίας της κλιματιστικής μονάδας. Πλήκτρο MODE Με αυτό το πλήκρο ρυθμίζετε την λειτουργία της κλιματιστικής μονάδας όπως παρακάτω: ➝ AUTO ➝ COOL ➝ DRY ➝ HEAT ➝ FAN ➝...
Seite 19
Λειτουργίες Πλήκτρων Πλήκτρο ( Πιέστε αυτό το κουμπί για να αυξήσετε την εσωτερική ρύθμιση της θερμοκρασίας σε βήματα 1°C έως 30°C. Πλήκτρο ( Πιέστε αυτό το κουμπί για να μειώσετε την εσωτερική ρύθμιση της θερμοκρασίας σε βήματα 1°C έως 17°C. Σημείωση: Η...
Seite 20
Λειτουργίες Πλήκτρων Πλήκτρο Swing Δεν διατίθεται σε αυτές τις σειρές. Πλήκτρο Swing (εφαρμόζεται στο RG57A4/BGEF) Με αυτό το πλήκτρο επιλέγετε την εκκίνηση ή διακοπή της κίνησης της οριζόντιας περσίδας ή ρυμθίζετε την επιθυμητή θέση των περσίδων και την διάχυση αέρα. Οι...
Ενδείξεις στην LCD οθόνη Ενδείξεις λειτουργιών Οι ενδείξεις εμφανίζονται όταν το τηλεχειριστήριο είναι AU TO COOL ενεργοποιημένο HE AT Ένδειξη μετάδοσης εντολών Εμφανίζεται όταν το τηλεχειριστήριο είναι ενεργοποιημένο Ένδειξη μπαταρίας (ανίχνευση χαμηλής μπαταρίας) Δεν είναι διαθέσιμο σε αυτή τη μονάδα Εμφανίζεται...
Χρήση των πλήκτρων Αυτόματες λειτουργίες Βεβαιωθείτε πως η κλιματιστική μονάδα είναι συνδεδεμένη με την παροχή ρεύματος. Η ενδεικτική λυχνία OPERATION (λειτουργίας) στην οθόνη της εσωτερικής μονάδας είναι αναμμένη. 1. Πιέστε το πλήκτρο MODE και επιλέξτε Auto. 2. Πιέστε το πλήκτρο UP/DOWN για να ορίσετε την επιθυμητή...
Χρήση των πλήκτρων Λειτουργία Αφύγρανσης Βεβαιωθείτε πως η κλιματιστική μονάδα είναι συνδεδεμένη με την παροχή ρεύματος . Η ενδεικτική λυχνία OPERATION (λειτουργίας) στην οθόνη της εσωτερικής μονάδας θα είναι αναμμένη. 1. Πιέστε το πλήκτρο MODE για να επιλέξετε την λειτουργία DRΥ. 2.
Λειτουργία TIMER Με το πλήκτρο TIMER ON μπορείτε να ρυθμίσετε την αυτόματη ενεργοποίηση της μονάδας και με το πλήκτρο TIMER OFF την αυτόματη απενεργοποίηση της μονάδας. Ρύθμιση της ώρας της αυτόματης ενεργοποίησης της μονάδας. 1. Πιέστε το πλήκτρο TIMER ON. Στην οθόνη του ασύρματου...
Seite 25
ΠΡΟΣΟΧΗ • Οταν επιλέξετε την λειτουργία ΤΙΜΕR, το τηλεχειριστήριο μεταδίδει αυτόματα το σήμα χρονδιακόπτη στην εσωτερική μονάδας για το καθορισμένο χρόνο. Ως εκ τούτου το τηλεχειριστήριο θα πρέπει να βρίσκεται σε θέση όπου μπορεί να μεταδίδει το σήμα στην εσωτερική μονάδα σωστά. •...
Seite 26
TIMER OFF (Αυτόματη απενεργοποίηση της μονάδας) Η λειτουργία TIMER OFF είναι χρήσιμη όταν θέλετε να απενεργοποιηθεί η μονάδα όταν πέσετε για ύπνο. Η κλιματιστική μονάδα θα απενεργοποιηθεί αυτόματα την ώρα που έχει επιλεγεί. Τερματισμός Παράδειγμα: λειτουργίας Διακοπή λειτουργίας της κλιματιστικής μονάδας μετά Εκκίνηση...
Seite 27
Εκκίνηση λειτουργίας ➝ Διακοπή λειτουργίας Αυτή η λειτουργία είναι χρήσιμη όταν θέλετε η κλιματιστική μονάδα να ενεργοποιηθεί πριν ξυπνήσετε και να διακόψει τη λειτουργία της όταν φύγετε από το σπίτι. Εκκινήση Λειτουργίας Παράδειγμα: Απενερ- Τερματισμός γοποίηση Ενεργοποίηση της κλιματιστικής μονάδας 2 ώρες μετά λειτουργίας...
Χειρισμός του Ασύρματου Τηλεχειριστηρίου Θέση του Ασύρματου Τηλεχειριστηρίου • Να χρησιμοποιείτε το ασύρματο τηλεχειριστήριο εντός 8μ από την κλιματιστική μονάδα στοχεύοντας στον δέκτη σήματος. Η αποδοχή της εντολής συνοδεύεται από ένα ήχο. ΠΡΟΣΟΧΗ • Η κλιματιστική μονάδα δεν θα λειτουργεί αν...
Αντικατάσταση μπαταριών Αντικαταστήστε τις μπαταρίες όταν δεν ακούτε τον αντίστοιχο ήχο από την εσωτερική μονάδα ή όταν η ένδειξη εντολής στο ασύρματο τηλεχειριστήριο δεν ανάβει. Το ασύρματο τηλεχειριστήριο χρειάζεται 2 ξηρού τύπου μπαταρίες (R03/LR03X2) που βρίσκονται στην πίσω πλευρά του. (1) Αφαιρέστε...
Seite 30
CUPRINS Specificatiile telecomanzii ..............Tastele de functionare ............... Indicatiile afisajului ................Cum sa folosim tastele ................ Functionarea Auto ................Racire / Incalzire / Ventilare ..............Functia de dezumidificare ..............Functia de programare ................ Fixarea de perete a telecomanzii ............NOTA: de Utilizare pe descrierea functiei, descrierea din MANUALUL DE...
Seite 34
Functiile tastelor Tasta de miscare a flapsurilor stanga dreapta (aplicabil pentru RG57A4/BGEF). (care nu sunt incluse în acest model) Tasta de miscare a flapsurilor sus jos verticala a flapsurilor sau setarea in stanga sau r. Flapsul isi mai mult de 2 secunde, flapsurile se vor misca RG57(A2)A3/BGEF) Follow Me, iar temperatura afisata pe telecomanda este cea reala unde este aceasta...
Seite 35
Indicatori pe afisaj Mod afisaj Indicatorii sunt afisati cand telecomanda AUTO RACIRE DEZUMIDIFICARE este activata. INCALZIRE VENTILARE Se afiseaza cand se trimite semnalul. Se afiseaza cand telecomanda este pornita Afisaj baterie (detectare baterie descarcata) Nu este disponibil pentru acest aparat Se afiseaza cand Pornirea Programata este activata.
Cum sa folositi tastele Functionare auto Asigura i-v c aparatul este conectat i alimentat cu energie electrica. Indicatorul de func ionare de pe panoul de afi aj al unit ii interioare începe s clipeasc . 1. Ap sa i butonul MODE pentru a selecta Auto.
Cum sa folositi tastele Functionarea in Dezumidificare Asigura i-v c aparatul este conectat i alimentat cu energie electrica. Indicatorul de func ionare de pe panoul de afi aj al unit ii interioare începe s clipeasc . 1. Ap sa i butonul MODE pentru a selecta modul DEZUMIDIFICARE.
Seite 44
INHALT Technische Daten der drahtlosen Fernbedienung ............3 Tastenfunktionen ........................ 4 Anzeigen auf dem LCD-Display ..................7 Tastenbedienung ......................... 8 Automatikbetrieb ........................ 8 Kühl-/Heiz-/Lüftermodus ....................8 Entfeuchtungsmodus ......................9 Timer-Betrieb ........................10 Betrieb der drahtlosen Fernbedienung ................14 Hinweis: • Das Design der Tasten kann sich ein wenig von das von Ihnen erworbene unterscheiden •...
Technische Daten der Drahtlosen Fernbedienung Modell RG57A4/BGEF,RG57A6/BGEF Nennspannung 3.0V (Trockenbatterien R03/LR03X2) Empfangssignalreichweite Umgebungstemperaturbereich -5°C~ 60°C ON/OFF TIMER MODE TEMP TIME R SLEEP FRESH TURBO SELF CLEAN LED FOLLO W ME RG57A4/BGEF...
Tastenfunktionen Taste ON/OFF : Mit dieser Taste wird der Betrieb der Klimaanlage ein- und ausgeschaltet. MODE-Taste Mit dieser Taste stellen Sie den Betriebsmodus der Klimaanlage wie folgt ein: ➝ AUTO ➝ COOL ➝ DRY ➝ HEAT ➝ FAN ➝ (Automatik)➝(Kühlung)➝(Trocknung)➝(Lüfter) Hinweis: Der Heiz-Modus gilt nicht für Geräte, die nur für Kühlung bestimmt sind.
Seite 47
Tastenfunktionen Taste ( Drücken Sie diesen Knopf um die Innentemperaturregelung stufenartig von 1°C bis 30°C zu erhöhen. Taste ( Drücken Sie diesen Knopf um die Innentemperaturregelung stufenartig von 1°C bis 17°C zu reduzieren. Hinweis: Die Temperaturregelungsfunktion ist im Lüfterbetrieb nicht verfügbar. Taste SILENCE/FP •...
Seite 48
Tastenfunktionen Swing Taste Für diese Baureihe nicht verfügbar. Swing Taste (gilt für RG57A4/BGEF Mit dieser Taste können Sie Start bzw. Unterbrechung der Bewegung der horizontalen Lamellen wählen oder die gewünschte Position der Lamellen und der Luftströmung einstellen. Die Position der Lamellen ändert sich mit jedem Knopfdruck um 6 Grad.
Anzeigen auf dem LCD-Display Betriebsanzeigen Die Anzeigen erscheinen wenn die Fernbedienung AU TO COOL aktiviert ist HE AT Signalübertragungsanzeige Sie erscheint wenn die Fernbedienung aktiviert ist Batterieanzeige (Batterieerschöpfungsdetektion) Nicht verfügbar für dieses Gerät Erscheint wenn TIMER ON eingestellt ist. Erscheint wenn TIMER OFF eingestellt ist Es erscheint die eingestellte Temperatur bzw.
Tastenbedienung Automatische Funktionen Stellen Sie sicher dass das Klimagerät an die Stromversorgung angeschlossen ist. Die Kontrollleuchte OPERATION (Betrieb) im Display der Inneneinheit leuchtet. 1. Drücken Sie die Taste MODE und wählen Sie Auto. 2. Drücken Sie die Taste UP/DOWN um die gewünschte Temperatur zu bestimmen.
Tastenbedienung Entfeuchtungsmodus Stellen Sie sicher dass das Klimagerät an die Stromversorgung angeschlossen ist. Die Anzeigeleuchte OPERATION (Betrieb) im Display der Inneneinheit leuchtet. 1. Drücken Sie die Taste MODE um den Betrieb DRΥ zu wählen. 2. Drücken Sie die Taste UP/DOWN um die gewünschte Temperatur zu wählen.
Timer-Betrieb Mit der Taste TIMER ONkönnen Sie die automatische Aktivierung und mit der Taste TIMER OFFdie automatische Deaktivierung des Geräts einstellen. Einstellung der Uhrzeit für die automatische Aktivierung des Geräts. 1. Drücken Sie die Taste TIMER ON. Auf dem Display der drahtlosen Fernbedienung erscheint die Anzeige TIMER ON, die vorherige Uhrzeiteinstellung und die Anzeige „H“.
VORSICHT • Wenn sie die Funktion ΤΙΜΕR wählen, überträgt die Fernbedienung automatisch das Zeitschaltsignal an die Inneneinheit für die definierte Zeit. Daher, muss sich die Fernbedienung an einer Stelle befinden, aus der sie das Signal korrekt an die Inneneinheit übertragen kann. •...
Seite 54
TIMER OFF (Automatische Deaktivierung des Geräts) Die Funktion TIMER OFF ist nützlich wenn Sie das Gerät deaktivieren möchten bevor Sie schlafen gehen. Das Klimagerät deaktiviert sich automatisch zur eingestellten Uhrzeit. Beenden Zum Beispiel: des Betriebs Betriebsunterbrechung des Klimageräts nach 10 Start Stunden.
Seite 55
Betriebsstart ➝ Betriebsunterbrechung Diese Funktion ist nützlich wenn Sie wünschen dass das Klimagerät bevor Sie aufwachen eingeschaltet und nachdem Sie Ihr Haus verlassen abgeschaltet wird. Starten des Zum Beispiel: Betriebes Einschalten des Klimageräts 2 Stunden nach der Beenden Ausschalten Einstellung und Start des Betriebsunterbrechung 5 des Betriebs Stunden nach der Einstellung.
Betrieb der drahtlosen Fernbedienung Position der drahtlosen Fernbedienung • Benutzen Sie die drahtlose Fernbedienung innerhalb eines Abstands von 8 m vom Klimagerät und zielen Sie auf den Signalempfänger. Der Empfang des Signals wird durch einen Ton begleitet. VORSICHT • Das Klimagerät funktioniert nicht wenn Befehle von der Fernbedienung an die Inneneinheit durch Vorhänge, Türen oder andere Gegenstände behindert wird.
Batterieaustausch Tauschen Sie die Batterien aus wenn Sie nicht den entsprechenden Ton hören oder wenn keine Anzeige auf dem Display sichtbar ist. Die drahtlose Fernbedienung braucht 2 Trockenbatterien, (R03/LR03X2), die sich auf der Rückseite befinden. (1) Entfernen Sie die Abdeckung. (2) Batterien herausnehmen, die neuen einsetzen und dabei auf richtige Polung achten (+) und (-).
AIR CONDITIONING SYSTEMS REMOTE CONTROLLER Please check the applicable models, F-GAS and manufacturer information from the “Owner’s Manual - Product Fiche” in the packaging of the outdoor unit. (European Union products only).
