Attach the Adapter to the Power Supply
1. Select the proper adapter. Each adapter has a slot into which the
retaining latch on the power supply fits.
2. Place the adapter onto the power supply so that the tabs on
the adapter are aligned with their respective slots on the power
supply (Figure 3).
3. Slide the adapter into the power supply until a click is heard and
the adapter is locked in place.
NOTE: When correctly mounted, the adapter will not rock or move.
If the adapter feels loose, remove it and re-install. Use only Kerr
supplied power supply (part number 35815).
Remove the Adapter from the Power Supply
1. Press on the latch retainer button; slide the adapter away from
the power supply, and remove the adapter (Figure 4).
2. Retain unused adapters for future use.
Using the Charging Dock
The Demi Ultra System uses a power source that recharges very quickly. The unit is shipped uncharged and
requires charging for first use. Follow these instructions for effective operation:
1. Plug the power supply into an electrical outlet.
2. Plug the power supply into the Charging Dock. The socket is located at the back of the Charging Dock
(Figure 5).
3. Insert the Demi Ultra unit into the Charging Dock with the controls facing the radiometer. When charging,
the unit's indicator lights turn off and the charging dock charging indicator lights turn on. These are on the
upper and lower surface of the dock's "bridge" (Figure 5). Amber light indicates the unit is charging. Green
indicates the unit is fully charged.
When setting up the Charging Dock, always confirm you are using the correct cable. Place the Charging Dock as
close as possible to the wall outlet. Never allow the cord to drape across an open space where it can be
accidentally pulled. When moving the Charging Dock, unplug it from the wall outlet by hand and remove the
Curing Light Body. Never pull the cord from a distance. Unplug the cord from the Charging Dock only when
cleaning.
For Optimal Power Source Performance
When recharged regularly, the Demi Ultra requires only 40 seconds for a full recharge. If the power source
fully drains after several days of inactivity, the unit may require up to 70 seconds for a full recharge. After fully
recharging, the unit will again require only 40 seconds for subsequent recharges if operation is regular as stated
above.
A full recharge yields approximately 250 seconds of run time, or twenty-five (25) 10 second cures.
Amber = Charging
Green = Charged
Figure 5 – Charging Indicator Lighting
7
Figure 3 – Electrical Power Supply
with an Adapter
Figure 4 – Removing the Adapter
