OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any
commercial DMX controller as well as wireless via QuickDMX with the optional available EUROLITE
QuickDMX USB Wireless Transmitter/Receiver.

Menu structure

Mode
DMX mode
Preset colors
Automatic mode
Sound control
Running speed in
automatic mode and
sound
Microphone sensitivity
for sound control
Dimmer
Sound control silent
scene
Behavior in case of
missing DMX signal
Slave mode
IR remote control
Firmware version
Display
d001-512
12CH
Addr
d001-512
5CH
Stat S 01-25
Auto Au 1 – 4
Soun So 1 – 4
SPEE SP 1-9
SEnS SE 1-9
diMM dI 1-dI 9
on
SILE
oFF
blac
Hold
Lost Full
Stat
Auto
SLAV Slave
on
InFr
oFF
Vxx Vxx
25/32
Function
12-channel mode and start address
5-channel mode and start address
Constant lighting in one of 25 colors
Auto program
Sound program
Program running speed
slow > fast
Microphone sensitivity
low > high
Total brightness
dark > bright
LEDs off if there is no music signal
LEDs remain on if there is no music signal
LEDs switched off
Most recent DMX value is held
All LEDs 100% on
Pre-selected static color 01-25
Pre-selected auto program 01-04
Master/Slave operation
IR remote control on
IR remote control off
Firmware version number
00136925, Version 1.0
