Connection with the mains

Connect the device to the mains with the power plug.
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.

OPERATION

After connecting the EUROLITE LED BCW-4 Beam Effect to the mains, it starts running.

CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers. Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer. Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of LEDs up:
Number of LEDs down:
Dimensions (LxWxH):
Maximum ambient temperature T
Max. housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Weight:
Please note: Every information is subject to change without prior notice. 11.03.2014 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
100 - 240 V AC, 50/60 Hz ~
7 W
3x 1W LEDs (RGB)
48 LEDs 5 mm(RGB)
128 x 128 x 130 mm
: 45° C
a
(steady state): 70° C
C
0.50 m
0.10 m
0.3 kg
13/13 00082141.DOC, Version 1.0
