3.2

EU Declaration of Conformity

We herewith declare, with sole
responsibility, that this product conforms
to the following standards or normative
documents:
EN62841-1:2015+AC:2015
EN62841-2-1:2018
In accordance with the provisions of the
2014/30/EU
2006/42/EC
2011/65/EU
in conjunction with the safety instructions
documented in the instruction manual and
the specified intended use.
The head of development is authorised to write the
technical documents.
These are available from:
Maschinenfabrik OTTO BAIER GmbH,
Heckenwiesen 26,
71679 Asperg
Germany
Thomas Schwab
Managing Director
Asperg, 26/02/2021
3.3

Machine characteristics

The compact 18 V cordless dry diamond drill with
soft impact feature has been designed specially for
drilling socket outlets.
The machine has specially developed electronics.
It monitors the speed and switches the machine off
automatically in the event of sudden rotation of the
power tool about the drill axis, e.g. due to catching
or jamming of the insert tool.
The motor is protected from overheating by a
thermal overload protection device. A warning
signal (bleep) sounds if the overload protection is
activated.
The machine is also equipped with a selectable
soft impact mechanism. It protects the diamond
segments of the socket outlet drill bits, allows faster
working and carries the drill dust away from the
diamond segments. This in turn achieves a longer
tool life for the socket outlet drill bits.
ABDB 82, V01 / 2021-03
Directives
Robert Pichl
Factory Manager
An optimally shaped vacuum cleaner adapter
with insertable centring pin enables dust-free and
precise working.
3.4

Machine parts and controls

Overview
1
1 Hammer drilling slide switch
Left position: Hammer drilling ON
Right position: Hammer drilling OFF
2 Transport lock
3 ON / OFF press switch with speed control
4 Handle
5 Battery pack release
6 Battery pack
7 Capacity indicator button
8 Capacity indicator LEDs
9 Overheating protection LEDs
10 Vacuum cleaner adapter
11 Centring pin
12 Socket outlet drill bit
13 Additional handle
3.5

Intended use

The ABDB 82 machine, together with drill bits for
socket outlets, is intended to be used to drill holes
(cores) for socket outlets in mineral materials such
as calcium silicate, bricks, Poroton, plaster and
exposed aggregate concrete.
Never work without extraction.
Observe the relevant regulations in your
country for the materials to be machined and
extraction.
Do not drill in the following materials: Wood, metal,
reinforced concrete and glass, etc.
The user is solely liable for damage caused by
non-intended use.
| 35 |
